Description
48V phantom power supply, fully discrete circuit design with a dual-transistor class A buffer circuit structure combined with custom audio transformer, achieving excellent signal fidelity and transmission capabilities.
FEATURES:
- 48V phantom power supply, no battery required
- Megohm-level input impedance
- Extremely high dynamic headroom, handles high-level instruments with ease
- Chain port supports direct through and buffered switchable output
- Audio isolating output transformer
- 48V power supply with LED button indication
- Fully discrete circuitry
- Signal phase reverse shifter
- GND lift shifter
SPECIFICATIONS:
- Total harmonic distortion:0.002%@-5dBu
- Phase Deviation:2°@20Hz; 0°@1kHz
- Dynamic range:118dB
- Noise Floor:Below 0 dBu
- Frequency response:20Hz-20kHz(±0.2dB)
- Input Impedance:1M Ohms, unbalanced
- Output Impedance:200 Ohms, balanced
